1080P HDMI Microscope Camera

Overview
The HD Lite is a streamlined HDMI CMOS Camera designed for fast image and video capture, with a built-in perfect color restoration algorithm, image acquisition, and processing functions. No computer is required to operate the camera, making it extremely easy to use.

5MP CMOS Camera

The HD Lite uses a new 5 Megapixel HD image sensor. The detail of the subject is clearly presented, providing excellent image quality.

Perfect Color Reproduction

Tucsen’s HD Lite camera can process colour with a completely new level of precision, resulting in extremely-high color definition, perfectly matching the monitor image to the eyepiece view.

Intelligent Image Processing

The HD Lite automatically analyzes the acquired images and optimizes the white balance, exposure time and saturation to present perfect images. Whether it is used for brightfield bioimaging or darkfield birefringent crystal imaging, the HD Lite delivers incredible images with minimal need for parameter adjustment.

Specification >

• Model:HD Lite
• Sensor Type:CMOS
• Sensor Model:SONY IMX335LQN-C
• Color/Mono:Color
• Array Diagonal:6.54 mm (1/2.8″)
• Resolution:2 MP, 2592 (H) x 1944 (V)
• Pixel Size:2.0 μm x 2.0 μm
• Effective Area:5.7 mm x 3.8 mm
• Shutter Mode:Rolling
• Frame Rate:15 fps @ USB2.0, 30 fps @ HDMI
• Exposure Time:1 ms – 2 s
• SD Format:FAT32
• Color Temperature:1800-10000 K
• Software:HDMI: Cloud, USB: Mosaic V2 / Mosaic V3
• HDMI Key Settings:Preview: 1920 x 1080; Capture: 2592 x 1944; Vedio recording: 30 fps @1920 x 1080
• Picture Format:HDMI: JPG/TIF; USB: TIFF/JPG/PNG/DICOM
• Multiple Cameras:Supports 4 Cameras Simultaneously in SDK
• Optical Interface:Standard C Mount
• Power:2.4 W
• Dimensions:90.7 mm x 74 mm x 67.2 mm
• Weight:265 g
• Data Interface:HDMI, USB2.0, SD card
• Operating Environment:Temperature: -10~45 ℃; Humidity: 10%~85%
• Operating System:Windows 7/10 (32 Bit/64 Bit)/Mac
• PC Configuration:CPU: Intel Core i5 or better(Quad or more Core); RAM: 8G or more
